Mi Router AX1800

External dimensions
247X141x180 mm

Product colour
White

product name
Mi Router AX1800

Processor
IPQ6000 quad-core A53 1.2 GHz CPU

Network Acceleration Engine
Single-core 1.5 GHz NPU

Memory
256 MB

2.4G Wi-Fi
2×2 (supports up to IEEE 802.11ax protocol with a theoretical maximum speed of 574 Mbps)

5G Wi-Fi
2×2 (supports up to IEEE 802.11ax protocol, theoretical maximum speed up to 1201 Mbps)

Antennas
4x external antennas

Cooling
Passive cooling

Product ports
1x 10/100/1000M adaptive WAN port (Auto MDI/MDIX)
3x 10/100/1000M adaptive LAN ports (Auto MDI/MDIX)

LED indicator
2x (System indicator x1, Internet indicator x1)

System reset button
1x

Power supply port
1x

Protocol standards
IEEE 802.11 a/b/g/n/ac/ax,
IEEE 802.3/3u/3ab

Certification standards
GB/T9254-2008;
GB4943.1-2011

Dual band
2.5 GHz and 5 GHz

Modulation

11B:DSSS:DBPSK(1 Mbps), DQPSK(2 Mbps), CCK(5,5/11 Mbps)
11A/g:OFDM:BPSK(6/9 Mbps), QPSK(12/18 Mbps), 16QAM(24/36 Mbps),
64QAM(48/54 Mbps)
11n:MIMO-OFDM:BPSK,QPSK,16QAM,64QAM.Rate set: MCS0-MCS15
11AC:MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM.
Rate set: MSC0-MCS9 (supports 2 streams)
11ax:MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM,1024QAM.
Rate set: MCS0-MCS11 (2 streams supported)

Operating system
OpenWRT widely customisable intelligent router operating system MiWiFi ROM

WiFi Encryption
WPA-PSK/WPA2-PSK/WPA3-SAE encryption,wireless access control (blacklist and whitelist),
SSID hiding, smart unauthorized access prevention

Network Security:
Access control (blacklist, whitelist), guest network, DoS, SPI firewall,
IP and MAC Address binding, IP and MAC filtering

Manage applications
Supports Web, Android, iOS

Operating environment temperature
0°C–40°C

Operating humidity
10%–90% RH (non-condensing)

Storage temperature
-40°C–70°C

Storage humidity
5%–90% RH (non-condensing)
